Page 14

English

5. For safe operation

the manual.

1.Grip the handles firmly with both hands using your whole hand. Place your feet slightly apart (slightly further apart than the width of your shoulders) so that your weight is distributed evenly across both legs, and always be sure to maintain a steady, even posture while working.

2.Keep cutting attachment below waist level.

3.Maintain the speed of the engine at the level required to perform cutting work, and never raise the speed of the engine above the level necessary.

4.If the unit starts to shake or vibrate, turn off the engine and check the whole unit. Do not use it until the trouble has been properly corrected.

5.Keep all parts of your body away from rotating cutting attachment and hot surfaces.

6.Never touch the muffler, spark plug, or other metallic parts of the engine while the engine is in operation or immediately after shutting down the engine. Doing socould result in serious burns or electrical shock.

7.While operating the machine be always sure of a safe and secure operating position especially when using steps or a ladder.

• IF SOMEONE COMES

1.Guard against hazardous situations at all times. Warn adults to keep pets and children away from the area. Be careful if you are approached. Injury may result from flying debris.

2.If someone calls out or otherwise interrupts you while working, always be sure to turn off the engine before turning around.

MAINTENANCE

1.In order to maintain your product in proper working order, perform the maintenance and checking operations described in the manual at regular intervals.

2.Always be sure to turn off the engine before performing any maintenance, checking procedures or working on the machine.

(1) Check ok!

WARNING

The metallic parts reach high temperatures immediately after stopping the engine.

14
