Black Box KV1424A-R2 What to do if the Admin password has been forgotten, Configuration screens

What to do if the ADMIN password has been forgotten

If the ADMIN password becomes mislaid or forgotten, you will not be able to access the ServSwitch CX to add or edit users and server names. This situation may be resolved by performing a complete reset to return the ServSwitch CX or CX with IP to its factory default state.

IMPORTANT: A complete reset erases all the user names and server names that you have setup.

Slightly different procedures are used to reset the ServSwitch CX and the ServSwitch CX with IP, as detailed here.

To reset ServSwitch CX models

1Remove all power inputs from the ServSwitch CX unit.

2Move switch 3 on the rear panel down to the ON position.

3Press and hold the front panel USER and COMPUTER buttons while you re- apply power. On the local user port, a screen menu will indicate that the unit has been reset and will prompt you to power down and return the switch to its normal position.

4As directed, remove power and move switch 3 up to its OFF position.

5Power up and configure the unit in the normal manner.

®

To reset the ServSwitch CX with IP models		
1	Remove all power inputs from the ServSwitch CX with IP unit.
2	Move switch 2 on the rear panel down to the ON position.	
3	Re-apply power to the unit. On the local user port, a screen menu will
	provide two options.
4	Using the local keyboard or mouse, select the ‘Reset Configuration’ option.
	A warning screen will be displayed, select the RESET option and press .
	The unit will reset and then prompt you to work through the initial IP
	configuration screens.
5	After you have completed the initial IP configuration, remove power and	
	move switch 2 up to its OFF position.
		 



34
