Page 29

ROTISSERIE SPIT ROD AND FORKS

Cleaning Method:

Wash with mild detergent, using a soft cloth and warm water.

Rinse and dry.

For stubborn areas, use a multi-purpose cleaner, a heavy- duty scrub sponge or mild abrasive cleaner.

DRAWERS

Cleaning Method:

Routine cleaning

Paper towel and spray glass cleaner:

Make sure drawer is cool. Follow manufacturer’s instructions.

Warm, soapy water or all-purpose cleaner and a nonabrasive, plastic scrubbing pad:

Wash, wipe with clean water and dry thoroughly.

Stubborn stains and baked-on residue

Rub in direction of grain to avoid damaging.

Mildly abrasive cleanser or stainless-steel cleaners and a damp cloth or sponge.

Wash, wipe with clean water and dry thoroughly. Repeat if necessary.

RACKS

Cleaning Method:

Steel-wool pad and warm, soapy water: Wash, rinse and dry thoroughly.

Drawer Slides

The drawer slides allow you to fully extend the drawer for easier cleaning. If necessary, the drawer can be removed.

NOTE: Load capacity for the drawer and slides is 100 lbs (45 kg).

Drawer Removal

Remove all items from inside the warming drawer, and allow the warming drawer to cool completely before attempting to remove the drawer.

To Remove:

1.Open drawer to its full open position.

2.Locate the black tabs on both sides of the drawer.

A

A. Tab

3.Press the tab down on the right side and lift tab up on the left side at the same time, then pull drawer out another inch to disengage latch.

4.Hold the drawer by its sides (not by its front). Pull it slowly all the way out.

To Replace:

1.Align the drawer glides with the receiving guides.

B

A

A. Drawer glides

B. Receiving guides

2.Push drawer in all the way.

3.Gently open and close the drawer to ensure it is seated properly on the guides.

TROUBLESHOOTING

Try the solutions suggested here first in order to avoid the cost of an unnecessary service call.

Nothing will operate

Is the main or regulator gas shutoff valve in the off position?

See Installation Instructions.

Is the grill properly connected to the gas supply? Contact a trained repair specialist or see Installation Instructions.

WARNING

Electrical Shock Hazard

Plug into a grounded 3 prong outlet.

Do not remove ground prong.

Do not use an adapter.

Do not use an extension cord.

Failure to follow these instructions can result in death, fire, or electrical shock.

Is the power supply cord unplugged? Plug into a grounded 3 prong outlet.

Has a household fuse blown, or has a circuit breaker tripped?

Replace the fuse or reset the circuit breaker. If the problem continues, call an electrician.

29

Image 29
