ASUS P5B Deluxe A-1

A.1 Intel® EM64T

• The motherboard is fully compatible with Intel® Pentium® 4 LGA775

processors running on 32-bit operating systems.

• The motherboard comes with a BIOS le that supports EM64T. You can

download the latest BIOS le from the ASUS website (www.asus.com/

support/download/) if you need to update the BIOS le. See Chapter 4 for

details.

• Visit www.intel.com for more information on the EM64T feature.

• Visit www.microsoft.com for more information on Windows® 64-bit OS.

Using the Intel® EM64T feature

To use the Intel® EM64T feature:

1. Install an Intel® Pentium® 4 CPU that supports the Intel® EM64T.

2. Install a 64-bit operating system (Windows® XP Professional x64 Edition or

Windows® Server 2003 x64 Edition).

3. Install the 64-bit drivers for the motherboard components and devices from

the support CD.

4. Install the 64-bit drivers for expansion cards or add-on devices, if any.

Refer to the expansion card or add-on device(s) documentation, or visit the

related website, to verify if the card/device supports a 64-bit system.

A.2 Enhanced Intel SpeedStep®

Technology (EIST)

• The motherboard comes with a BIOS le that supports EIST. You can

download the latest BIOS le from the ASUS website (www.asus.com/

support/download/) if you need to update the BIOS. See Chapter 4 for

details.

• Visit www.intel.com for more information on the EIST feature.

A.2.1 System requirements

Before using EIST, check your system if it meets the following requirements:

• Intel® Pentium® 4 processor with EIST support

• BIOS le with EIST support

• Operating system with EIST support (Windows® XP SP2/Windows® Server

2003 SP1/Linux 2.6 kernel or later versions)
