4.4.4CPU Configuration

The items in this menu show the CPU-related information that the BIOS automatically detects.

BIOS SETUP UTILITY

Advanced

Configure Advanced CPU settings

Module Version: 3C.0E

Manufacturer: Intel

Brand String: Genuine Intel(R) CPU 3.20GHz

Frequency	:	3.2GHz
FSB Speed	:	533 MHz
Cache L1	:	16 KB
Cache L2	:	256 KB
Ratio Status: Unlocked (Max:24, Min:14)
Ratio Actual Value : 14
CPUID	: F41

S e t s t h e r a t i o between the CPU core c l o c k a n d t h e F S B frequency

	Modify Ratio Support	[Disabled]
	C1E Support	[Enabled]
	Max CPUID Value Limit:	[Disabled]		Select Screen
	Vanderpool Technology	[Enabled]		Select Item
	CPU TM function:	[Enabled]	+-
				Change Option
	Execute Disable Bit	[Enabled]
			F1	General Help
	Hyper Threading Technology	[Enabled]
			F10	Save and Exit
	Intel(R) SpeedStep(tm) Tech.	[Disabled]
			ESC	Exit

v02.58 (C)Copyright 1985-2006, American Megatrends, Inc.

Modify Ratio Support [Disabled]

Configuration options: [Disabled] [Enabled]

The following item appears when the item Modify Ratio Support is set to Enabled.

Ratio CMOS Setting: [13]

C1E Support [Enabled]

Allows you to enable or disable C1E Support.

Configuration options: [Enabled] [Disabled]

Max CPUID Value Limit [Disabled]

Setting this item to [Enabled] allows legacy operating systems to boot even without support for CPUs with extended CPUID functions.

Configuration options: [Disabled] [Enabled]

Vanderpool Technology [Enabled]

Configuration options: [Enabled] [Disabled]

CPU TM function [Enabled]

Configuration options: [Disabled] [Enabled]

ASUS P5B Deluxe

4-21
