Memory Remapping Feature [Disabled]

Allows you to enable or disable the remapping of the overlapped PCI memory above the total physical memory. Enable this option only when you install 64-bit operating system.

Configuration options: [Disabled] [Enabled]

Configure DRAM Timing by SPD [Enabled]

Configuration options: [Enabled] [Disabled]

Initiate Graphic Adapter [PEG/PCI]

Allows you to decide which graphics controller to use as the primary boot device. Configuration options: [PCI/PEG] [PEG/PCI]

PEG Force x1 [Disabled]

Configuration options: [Enabled] [Disabled]

PEG Link Mode [Auto]

Configuration options: [Auto] [Slow] [Normal] [Fast] [Faster]

South Bridge Chipset Configuration

BIOS SETUP UTILITY

Advanced

South Bridge Chipset Configuration

PCIEX16_2/PCIEX1_1 Force

[Auto]

Options

Allows you to manually adjust PCIEX16_2/PCIEX1_1 configuration.

Select Screen

Select Item

+- Change Option

F1 General Help

F10 Save and Exit

ESC Exit

v02.58 (C)Copyright 1985-2006, American Megatrends, Inc.

PCIEX16_2/PCIEX1_1 Force [Auto]

Allows you to manually adjust PCIEX16_2/PCIEX1_1 configuration. Configuration options: [X2/X1 Mode (compatible)] [X4/disabled Mode (fast)] [Auto]

ASUS P5B Deluxe

4-23
