Setting up the network

70 Avaya VPNmanager Configuration Guide Release 3.7

Options for IP addressing for interface zones

You can configure each zone with different addressing options and the private port can be

configured as a DHCP server or DHCP relay used to obtain IP addresses from the DHCP

server (Table7). This section explains the options in detail.

* The DHCP Client for the private zone is for SG5/5X/200 and VSU5/5X/500 bootcode only.

Static addressing

Use static addressing if a dedicated IP address should be assigned to the public interface of the

security gateway. To configure static addressing, complete the following information:

DHCP addressing

Use DHCP addressing if the gateway obtains its IP address dynamically from the internet

service provider (ISP). This can be configured for public-backup.

Table 7: Type of IP addressing available by zone

Public Private Public-backup Semi-private DMZ Manage-ment

Address assigned

Static X X X X X X

DHCP Client X X* X

PPPoE X X

Server modes

Static X X X X

DHCP Server X X X

DHCP Relay X X

H.323 X X X X

Field Description

IP Address The public IP address that is assigned

to the security gateway

Network Mask The subnet mask

Route The IP address of the gateway router

to the Internet
