Monitoring your network
268 Avaya VPNmanager Configuration Guide Release 3.7

Monitoring wizard (Presentation)

The Monitoring presentation screen is used to select the display type for the monitored data.
The update frequency is also indicated here.

Presentation

There are four types of presentations:
Bar graph
Line graph
Pie chart
Tab le
Some types of data cannot be displayed in all four presentation styles. For example, only the
System Group can be presented as a bar graph.
Only the available presentation types appear in this field for the group previously selected (the
table is the most common format for most of the groups).
Update Time. - Update time defines how often your presentation is updated (security gateway
MIB is re-read). You can choose minutes or seconds.
Display. - The display area offers two selections for how your security gateway groups are
presented, either one window per security gateway, or a single window in which the desired
security gateway is selected from a drop-down menu.
Monitoring alarms
On the main VPNmanager window, the Alarm pane displays alarm information arriving f rom the
security gateways in the VPN. When an alarm arrives, a rotating red beacon light activates.
Conditions causing alarms include a security gateway device not reachable and several
security attacks, such as a manager authentication failure, a key failure, or a CCD failure. The
alarm console can also be used as a general trap target gather SNMP trap information from
other network devices.
Two buttons appear at the bottom of the pane: Properties, and Delete.
By default, all device alarms are displayed, however, alarms from a specific security gateway
can also be shown. All alarm information is stored locally on the VPNmanager Console.
