Dell PD598 Component Video and Standard Audio

Using CDs, DVDs, and Other Multimedia 65

Plug the other end of the digital audio cable into the S/PDIF input connector on your TV or other

audio device.

Turn on the TV, turn on any audio device that you connected (if applicable), and then turn on the

computer.

See "Enabling the Display Settings for a TV in Microsoft

Windows

XP" on page 70 to ensure that

the computer recognizes and works properly with the TV.

Component Video and Standard Audio

1S-video TV-out connector 2component video adapter

1component video adapter 2component video cable 3standard audio cable
