Phillips PM2.5×5.0 broadhead screw | HP HDX 16 specs

Phillips PM2.5×5.0 broadhead screw

Color	Quantity	Length	Thread	Head diameter

Silver	2	5.0 mm	2.5 mm	8.0 mm

Where used: 2 screws that secure the subwoofer to the base enclosure

Screw listing

7–12

Image 123

HP HDX 16 manual Phillips PM2.5×5.0 broadhead screw
