3.9 Main Battery Change Test 3. Tests and Diagnostics

3.8Main Battery Charge Test

NOTE: The AC adaptor (120W/90W, 19V) should be connected to successfully run this test.

This test shows and measures the main battery:

?Battery type (Ni-MH / Lion)

?Manufacturer (Sony / Sanyo)

?Remain charge capacity (0 ~ 100%)

?Charge function (PASS/FAIL)

- “Battery Is Full” showed when “remain charge capacity” is 100%

The screen should display as below, indicating whether the test is passed or failed when finished.

Tecra A3/S2 Series Maintenance Manual 3-13
