INTRODUCTION

Good Service

Husqvarna’s products are sold all over the world and only in specialized retail stores with complete service. This ensures that you as a customer receive only the best support and service. Before the product is delivered, the machine has, for example, been inspected and adjusted by your retailer, see the certificate in the Service Journal in this operator’s manual.

When you need spare parts or support in service questions, warranty issues, etc., please consult the following professional:

This Operator’s Manual belongs to machine with serial number:

Engine

Transmission

Manufacturing Number

The machine’s manufacturing number can be found on the printed plate affixed to the left in the engine compartment. Stated on the plate, from the top are:

The machine’s type designation (I.D.).

The manufacturer’s type number (Model).

The machine’s serial number (Serial no.)

Please state the type designation and serial number when ordering spare parts. The engine’s manufacturing number is stamped on one of the valve covers. The plate states:

The engine’s model.

The engine’s type.

Code

Please state these when ordering spare parts.

The Hydro Drive IZ gears have a barcode decal affixed to the rear of the gears.

English – 3
