BT Colour Printer If necessary, check the paper size setting, Install the starter print cartridge

Page 13

PaperJet 65 user guide – Edition 3 – 8.10.01

7If necessary, check the paper size setting

Your PaperJet 65 is preset to use standard A4 paper. If you need to use a different size you will need to change the setting as shown below.

To ensure your PaperJet is set to print on the paper size you are using, check the print format setting.

Press the Function button until the display shows FAX SET UP

Display shows DATE AND TIME

Press the Function button until the display shows PRINTER PARAMET

Display shows SIZE: A4

Press until the display shows the paper size you want.

To confirm the setting displayed.

Display shows AUTOMATIC RX

CHECK PRINT HEAD

8Install the starter print cartridge

Open the printer compartment cover.

Remove the print cartridge from its packaging. Holding it by the finger grip, peel the protective film from the print nozzles.

Avoid touching the nozzles and metal electrical contacts.

Insert the cartridge into the holder with the electrical contacts facing towards the front of the machine.

11

Image 13
