Cardio Program

119OM 8/28/06 11:43 AM Page 38

PROGRAM

PROFILE

Workout Programs, continued

Note: You may press the START key at any time during program setup to skip the adjust- ment and begin your workout. By doing so, the console will use default value of age and weight for %HR and calories burned calculations, and the default target HR for workout.

During the Program

Display

•This program cannot be started until a valid pulse is detected for 3 seconds. If no pulse is detected, the message window will flash a message “NO HR DETECTED”. Make sure your heart rate device is working properly. If the heart rate signal does not return, the display will continue to flash the “NO HR DETECTED” message and the current resistance level will not change until the heart rate signal returns.

•Once the program is started, the message window will display the workout data of “Time, Intensity Level, Watts, and Calories”.

•Press the “SELECT” key to switch the display to “% Max HR, Strides/Min, Distance, Strides”

•If no pulse is detected, the Pulse display will show “- - -” until there is a pulse, and the HR bar graph will not be illuminated.

•If a pulse is detected, the Pulse display will display the BPM, and the HR bar graph will illuminate to indicate your %Max. HR.

Adjusting % Max HR

•Press “UP/DOWN” key to adjust the % Max HR during the program. For the Fatburner program, the % Max HR can only be adjusted between 65% - 70%.

Pause, Reset, Switch, Stop or Save the program

See Basic Operation section for details.

Ending the Program

•When the selected program time is up or the “STOP” key is pressed, there will be a beep to signify the end of the program and Cool Down will become active

•The message window will scroll the messages “THE PROGRAM ENDED” then “3:00 COOL DOWN BEGIN”

•The “Start” key can be pressed to re-start the program.

•The “Stop” key can be pressed to skip the cool down mode and activate the Workout Summary immediately.

Getting Started

The Cardio Program provides an intense workout at 80% of your Max HR for high-level cardiovascular conditioning. The 1190 will adjust the intensity level to maintain 80% Max HR during the program. The profile on the Dot Matrix display will show % Max HR for this program rather than intensity level. The profile is replaced with LEDs indicat- ing your actual achieved HR as the program executes. The LEDs will blink to show your current position in the HR profile.

Beginning the Program

Start pedaling the unit. The message window will scroll a message “SELECT A PRO- GRAM”. Press the HR Interactive Programs key until the Cardio program LED indicator lights up.

36
	1190 Er Owner’s Manual
