LOCATION OF YOUR DRYER

Do Not Install Your Dryer:

1.In an area exposed to dripping water or outside weather conditions.

2.In an area where it will come in contact with curtains, thick carpet, or anything that will obstruct the flow of combustion and ventilation air.

3.On carpet, floor must be solid with a maximum slope of 1inch (2.54 cm). Any floor unevenness should be corrected with leveling legs located on the bottom of the dryer.

Installation in Alcove or Closet:

1.DO NOT install your dryer in a closet with a solid door.

2.A dryer installed in a bedroom, bathroom, alcove or closet MUST be exhausted outdoors.

3.No other fuel burning appliance shall be installed in the same closet as the gas dryer.

4.Refer to the images on this page to ensure the installation provides the minimum amount of clearance required for ventilation.

5.When installing the dryer in a closet with a door, a minimum of 120 square inches (774.2 square cm) of ventilation in the door is required. Openings must be equally divided at the top and bottom of the door and airflow must be unobstructed. A louvered door with equivalent air openings for the length of the door is acceptable.

10
