F-24	TROUBLESHOOTING & REPAIR	F-24
	TROUBLESHOOTING & REPAIR

FIRING BOARD TEST

TABLE F.1 - LED 7, 8 and 9 Check List

IF	THEN
LED 7 is ON	AC power is being supplied to the Firing Board from
	leads #203 and #204 connected to the phase angle wind-
	ing in the Main Transformer.

LED 7 is OFF or is DIM-	The proper AC voltage may not be reaching Firing Board.
MER than other LEDs	Check for loose or faulty connections. Perform Main
	Transformer Test.

LED 8 is ON	AC power is being supplied to the Firing Board from
	leads #205 and #206 connected to the phase angle wind-
	ing in the Main Transformer.

LED 8 is OFF or is DIM-	The proper AC voltage may not be reaching Firing Board.
MER than other LEDs	Check for loose or faulty connections. Perform Main
	Transformer Test.

LED 9 is ON	AC power is being supplied to the Firing Board from
	leads #207 and #208 connected to the phase angle wind-
	ing in the Main Transformer.

LED 9 is OFF or is DIM-	The proper AC voltage may not be reaching Firing Board.
MER than other LEDs	Check for loose or faulty connections. Perform Main
	Transformer Test.
