Cannon XL2 Camcorder Manual: Recording from Digital Video Devices

Recording from Digital Video Devices (DV Dubbing)

You can record from other digital video devices equipped with a DV terminal with virtually no loss in picture and sound quality.

1.Connect the camcorder to the digital video device.

See Connecting a Digital Video Device ( 93).

2.Set the POWER dial to VCR and load a blank cassette.

Make sure that [AV\DV] is set to [OFF] ( 98).

3.Connected device: Load the recorded cassette.

4.Press the 2 and a button (or the REC PAUSE button on the wireless controller).

In record pause mode and during recording, you can check the picture on the screen.

5.Connected Device: Play back the tape.

6.Press the a button (or the PAUSE a button on the wireless controller) when the scene you wish to record appears.

Recording starts.

7.Press the 3 button to stop recording.

•Press the a button to pause recording.

•Press the a button again to restart recording.

8.Connected Device: Stop playback.

❍Blank sections may be recorded as anomalous picture.

❍If the picture does not appear, reconnect the DV cable or turn the camcorder off and back on again.

❍You can only record signals from devices with the logo recording in SD system in SP or LP format.

❍When you press only the 2 button in step 4, recording starts immediately.

E

Editing

95

Image 95
