Canon C75 TX (Transmission) REPORT

TX (Transmission) REPORT

Your unit is factory-set to print a TX (transmission) REPORT only when an error occurs during sending. To change this setting, 1 TX REPORT, p. 14-5.

If you set the unit to print a report, a TX REPORT or an ERROR TX REPORT, similar to the ones below, will be printed depending on the setting you select.

27/12 2001 14:59 FAX 123 4567

CANON

001

	*********************
		*** TX REPORT		***
	*********************
		TRANSMISSION OK
		TX/RX NO	0003 :COLOUR TX
		CONNECTION TEL		1 432 2060
		CONNECTION ID	Canon OPTICS
		ST. TIME	12/27 14:59
		27/12USAGE2001 T14:59 FAX 123 4567	00’00	CANON		001
		PGS. SENT	0
		PGS. SENT	0
		RESULT	NG	#018
			BUSY/NO SIGNAL
			***************************
			***	ERROR TX REPORT	***
			***************************
		TX FUNCTION WAS NOT COMPLETED
		TX/RX NO		0004
		CONNECTION TEL			20 545 8545
		CONNECTION ID		Canon EUROPA
		ST. TIME		27/12 14:59
		USAGE T		00’18
		PGS. SENT		1
		RESULT		NG

THE SLEREXE COMPANY LIMITED

SAPORS LANE• BOOLE• DORSET• BH25 8ER

TELEPHONE BOOLE (945 13) 51617 – FAX 123456

Our Ref. 350/PJC/EAC

27 December, 2001

Dr. P. N. Cundall,

Mining Surveys Ltd.,

Holroyd Road,

Reading,

Berks.

“:COLOUR TX” INDICATES A COLOUR TRANSMISSION.

OK: TRANSMISSION SUCCESSFUL

NG: SOME OR NO PAGES SENT

NUMBER OF PAGES SENT

TRANSMISSION DURATION

TRANSMISSION TIME

IF YOU ENABLE THE PRINT WITH IMAGE SETTING (1 p. 14-5), THE FIRST PAGE OF THE FAX WILL PRINT ON THE REPORT TO REMIND YOU OF THE CONTENTS OF THE FAX (BLACK & WHITE FAXES ONLY).

11-4

Reports and Lists

Chapter 11
