Canon C75 ■BCI-21Colour BJ Tank, When to Replace a BJ Cartridge or BJ Tank

1 212

Download 212 pages, 2.12 Mb

■BCI-21 Colour BJ Tank

	B	Ca	Ink
	B		rtridge
		Cl-
	Color 21
JMade
apan	in

Contains the colour ink for the Colour BJ cartridge. When the Colour BJ tank of the Colour BJ cartridge runs out, replace with this tank.

When to Replace a BJ Cartridge or BJ Tank

How frequently you need to replace a BJ cartridge or tank depends on how you use your unit. If you print many graphics, halftones, or greyscales, you will need to replace them more often than if you print mainly text.

In general, you will need to replace a BJ cartridge in the following situations:

•If you have been using a BJ cartridge for over a year.

•If your printed output is not crisp and clear or has gaps in the characters (missing dots).

•If your colour printouts appear to be missing a colour.

•If the message CHANGE CARTRIDGE appears in the LCD.

In general, you will need to replace a BJ tank in the Colour BJ cartridge in the following situations:

•If you have been using a BJ tank for over six months.

•If your output is blank.

•If your printouts appear to be missing a colour.

•If the messages BLACK INK EMPTY and/or COLOUR INK EMPTY appear in the LCD.

Refer to the flow chart on the next page to check if the BJ cartridge or tank(s) need replacing.
