Canon C75 Cleaning the Rollers

5Clean the shaded area of the operation panel.

• Dirt and dust particles that collect on the underside of the operation panel affect the quality of the documents you copy or send.

6Use a clean, soft, dry, lint-free cloth to wipe up paper dust from the areas

(shaded) surrounding the separation roller.

SEPARATION ROLLER

7When you are finished, close the operation panel by pressing it down from the centre.

•Be sure to close the operation panel until it locks into place, or the unit will not function properly.

8Close the document tray.*

9Reconnect the power cord.

Cleaning the Rollers

You may need to clean the unit’s rollers after using a package of high resolution paper. This process removes paper dust from the unit’s rollers, preventing paper feed problems. For details, 1 p. 5-11.

* Hong Kong, Singapore, and Malaysia only.

12-6

Maintenance

Chapter 12
