Canon C75 Report Settings Menu

Report Settings Menu

For details on accessing the settings below, 1 pp. 14-2, 14-3.

Setting	Description	Sub-Settings
TX REPORT	Enables/disables automatic printing of a transmission	PRINT ERROR ONLY
	report. (1 p. 11-4)	OUTPUT YES
	PRINT ERROR ONLY: Prints a report only when a	OUTPUT NO
	transmission error occurs.
	OUTPUT YES: Prints a report every time you send a
	document.
	OUTPUT NO: No report is printed.
PRINT WITH	If you select PRINT ERROR ONLY or OUTPUT YES	ON
IMAGE	above, enables/disables printing of the first page of	OFF
	the fax under the report (black & white faxes only).

RX REPORT	Enables/disables automatic printing of a reception	OUTPUT NO
	report. (1 p. 11-5)	PRINT ERROR ONLY
	OUTPUT NO: No report is printed.	OUTPUT YES
	PRINT ERROR ONLY: Prints a report only when a
	reception error occurs.
	OUTPUT YES: Prints a report every time you receive a
	document.

ACTIVITY REPORT	Sets the ACTIVITY REPORT option. (1 p. 11-3)	–
AUTO PRINT	Enables/disables automatic printing of an ACTIVITY	ON
	REPORT after every 20 transactions.	OFF

Settings

Summary of

(Default settings are shown in bold type.)

Chapter 14

Summary of Settings

14-5
