IBM R400 Table 40. Parts list14.1-in. WXGA+ TFT (continued) No. FRU FRU no. RoHS ID, 43Y9638 R N

1 302

Download 302 pages, 6.4 Mb

Table 40. Parts list—14.1-in. WXGA+ TFT (continued)

No. FRU FRU no. RoHS

ID

CRU

ID

2 LCD cover kit for LED-backlight LCD v 6473-CTO v 6474-CTO, 1Gx, 1Hx, 42x, 43x, P9x, R5x, R6x, RCx,

RDx

v 6475-CTO, R2x v 7417-CTO, TSx v 7420-CTO, R2x v 7425-CTO v 7434-CTO v 2764-CTO, 26x, 27x, 42x, 43x, P1x, P2x, R1x, R2x v 2765-CTO, 24x, 25x, 26x, D1x, N5x, P5x, P6x, P7x, P8x,

R5x, R6x, R7x, R8x, T1x, T6x, T7x, T8x, T9x, TBx, TCx

v 2766-CTO, 17x, 18x, 19x, 1Ax, 1Bx, 1Cx, R1x, R2x v 2767-CTO, 1Tx, 1Vx, 1Xx, 1Yx, 1Zx, 21x, 23x, 29x,

2Gx, 2Hx, 2Jx, 2Kx, 2Lx, 2Mx, 45x, 46x, 47x, FBx, FCx,

FFx, FHx, FMx, FNx, FPx, FRx, FSx, FTx, FUx, FVx,

FWx, G2x, P1x, P2x, R1x, R2x, R3x, R5x, R7x

v 2768-CTO, P9x, R1x v 2769-CTO v 2773-CTO v 7438-CTO v 7439-CTO v 7440-CTO v 7443-CTO v 7445-CTO v 7446-CTO v 7447-CTO v 2782-CTO v 2783-CTO v 2784-CTO v 2786-CTO v 2787-CTO v 2788-CTO v 7789-CTO

43Y9638 R N

3 Wireless LAN/WAN/USB antenna assembly for T400 44C5366 R N 3 Wireless LAN/WAN/USB antenna assembly for T400 44C5367 R N 3 Wireless LAN/USB antenna kit for R400 44C5368 R N 3 Wireless LAN/USB antenna kit for R400 44C5369 R N

ThinkPad T400 and R400 255
