IBM R400 Table 17. Removal steps of keyboard (continued)

1 302

Download 302 pages, 6.4 Mb

Table 17. Removal steps of keyboard (continued)

Lift the keyboard a little in the direction shown by arrow 2, and then detach

the connector 3.

When installing: Make sure that the keyboard edges a are under the frame as

shown in this figure.

ThinkPad T400 and R400 75
