IBM R400 96

Table 25. Removal steps of fan assembly (continued)

- For R400 switchable graphics models:

v Make sure that the fan connector is attached firmly.

v When attaching the fan assembly to the frame, take care not to damage the

heat sink (b) of the fan assembly.

96 ThinkPad T400 and R400Hardware Maintenance Manual
