IBM R400 150

Table 38. Parts list—Overall (continued)

No. FRU FRU no. RoHS

ID

CRU

ID

12 SATA hard disk drive, 250 GB, 9.5 mm, 5,400 rpm OP

v 6473-CTO, D1x, D2x, D3x, D4x, L1x, L2x, N1x, P6x,

R3x, R4x, R5x

v 6474-CTO, 13x, 23x, P4x, R2x, R6x, R7x, RJx, RKx

v 6475-CTO

v 7417-CTO, 41x, 42x, L1x, T4x, TSx

v 7420-CTO, 11x

v 7425-CTO

v 7434-CTO

v 2764-CTO, 21x, 23x, 25x, 26x, 41x, P1x, P2x

v 2765-CTO, 21x, 22x, 2Kx, 2Lx, 2Qx, 2Rx, 31x, 32x, 43x,

L1x, N2x, N3x, N4x, N5x, N8x, P5x, P8x, R1x, R3x,

R4x, T1x, T2x, T6x, T9x, TBx, TCx, TDx

v 2766-CTO, 16x

v 2767-CTO, 17x, 19x, 1Px, 1Wx, 1Zx, 21x, 23x, 27x, 2Jx,

2Kx, 41x, 42x, 43x, 48x, 49x, F3x, FGx, FMx, FPx, FRx,

FUx, N5x, N6x, P2x, P4x, P5x, R5x, R7x

v 2768-CTO, 2Jx, C5x, N3x, P1x

v 2769-CTO

v 2773-CTO

v 7438-CTO

v 7439-CTO, 1Sx, E2x, E3x, N4x, N5x, P2x, V4x

v 7440-CTO, R1x, R2x, V5x

v 7443-CTO, C3x, N2x, P2x, P7x, P8x, PDx, PGx, R1x,

SAx, T5x, T7x, TCx, TFx, THx, TJx, TKx, TRx, TSx

v 7445-CTO, 12x, 19x, R1x, R2x, R3x

v 7446-CTO

v 7447-CTO

v 2782-CTO, 43x, 44x, 46x, 48x, N3x, P1x, P5x, PBx, R2x,

R3x, S1x, T2x, T5x, T7x, T9x, TKx, TMx, TNx, TPx,

TRx, TSx, TTx, TUx, TVx, TZx

v 2783-CTO

v 2784-CTO, 13x, 14x, R1x, R2x, R3x, R4x, R6x, V1x

v 2786-CTO, 13x, 14x, R2x, R3x, R4x

v 2787-CTO, 21x, 22x, 23x, P1x, P2x, P3x

v 2788-CTO

v 2789-CTO

42T1481 R **

150 ThinkPad T400 and R400Hardware Maintenance Manual
