1010 Battery pack

DANGER

Use only the battery specified in the parts list for your computer. Any other battery could ignite or explode.

Table 11. Removal steps of battery pack



Unlock the battery release lever

. Holding the battery release lever in the

unlocked position

, remove the battery pack in the direction shown by arrow

.





1



2

3

When installing: Install the battery pack along the slide rails of the slot. Then make sure that the battery release lever is in the locked position.

64ThinkPad T400 and R400Hardware Maintenance Manual
