Table 38. Parts list—Overall (continued)

No. FRU FRU no. RoHS

CRU

12 SATA hard disk drive, 320 GB, 9.5 mm, 5,400 rpm

v 6473-CTO

v 6474-CTO

v 6475-CTO

v 7417-CTO

v 7420-CTO

v 7425-CTO

v 7434-CTO

v 2764-CTO, 42x, 43x, R1x, R2x

v 2765-CTO, D1x, D2x, D3x, D4x, P4x, R2x, R5x, R6x,

R7x, R8x, T8x, TAx

v 2766-CTO, 17x, 19x, 1Bx, 1Cx, R1x

v 2767-CTO, 1Rx, 2Bx, 2Mx, 4Dx, E1x, E2x, F8x, FHx,

FVx, FWx

v 2768-CTO

v 2769-CTO

v 2773-CTO

v 7438-CTO

v 7439-CTO

v 7440-CTO, R3x

v 7443-CTO

v 7445-CTO, R4x, R5x

v 7446-CTO

v 7447-CTO

v 2782-CTO, N4x, PAx, R4x

v 2783-CTO

v 2784-CTO, V3x

v 2786-CTO, R5x

v 2787-CTO

v 2788-CTO

v 2789-CTO

42T1535 R **
