Solving service message issues

Troubleshooting

Solving service message issues

Problem

Service messages

Solution

A service message indicates printer failure that may require service. Turn the printer off, wait about 10 seconds, and then turn the printer on.

If the error recurs, write down the error number, the problem, and a detailed description. Call for service.

Solving paper feed problems

Symptom	Cause		Solution

Paper frequently jams.	You are using print media that		Try the following:
	does not meet the printer		• Flex the paper stack.
	specifications.		• Flex the paper stack.
	specifications.		• Turn the print media over.
			• Turn the print media over.
			Check the following:
			• Drawer is properly installed.
			• Print media is loaded correctly.
			• Print media is not damaged.
			• Print media meets printer specifications.
			• Guides are positioned correctly for the print media size
			selected.
			Use recommended print media.
			See the Card Stock & Label Guide available on the
			Lexmark Web site at www.lexmark.com for detailed
			specifications.
			For information that can help prevent jams from
			occurring, see Avoiding jams on page17.
	You have loaded too much print		Make sure the stack of print media does not exceed the
	media.		maximum paper fill indicators on the 250-sheet tray and /
			or the optional drawer.
	Guides in the selected tray are not		Move the tray guides to the correct position for the loaded
	set to the appropriate position for		print media size.
	the loaded print media size.
	The paper has absorbed moisture		• Load paper from a fresh package.
	due to high humidity.		• Store paper in its original wrapper until you load it.
			For more information, see Storing print media on
			page16.
The Paper Jam	You have not pressed	or have	Clear the entire paper path, and then press	. For more
message remains after	not cleared the entire paper path.		information, see Clearing a jam on page44.
you remove the jammed
paper.
The page that jammed	Jam Recovery in the Setup menu		Set Jam Recovery to Auto or On.
does not reprint after you	is set to Off.		For more information, see the Menus and Messages
clear the jam.			For more information, see the Menus and Messages
clear the jam.			Guide.
			Guide.
Blank pages feed into	The tray in use has an incorrect		Load the correct print media type for your print job, or
the output bin.	print media type loaded in it.		change the Paper Type to match the loaded print media
			type.
			For more information, see the Menus and Messages
			Guide.

Solving service message issues

54

Image 54
