OPERATION

1Press the MODE button to display OSD. The right-hand end numeral indicates INPUT FRE-

QUENCY.

Example: 31 kHz Input

V-POSI 31

051

OSD Display

IN/OUT/MODE DOWN

UP

2Press the MODE button to select the adjustment item.

(Each time the MODE button is pressed, the OSD display shifts sequentially in order of

V-POSI Å® H-POSI Å® V-SIZE Å® H-SIZE Å® CONTRAST Å® BRIGHT Å® DEGAUSS Å® RESET Å® OSD display disappears.)

Press the DOWN button while pressing the MODE button to return the adjustment item to the preceding one.

3Adjust with UP button and DOWN button.

4To exit from OSD, keep pressing the MODE button until the OSD display disappears.

V-POSI

The image' s vertical position is adjustable.

H-POSI

The horizontal image' s position is adjustable.

V-SIZE

The vertical image size is adjustable.

H-SIZE

The horizontal image size is adjustable.

CONTRAST

Adjusts image contrast.

BRIGHT

This adjusts the on-screen image brightness.

V-POSIH-POSI

V-SIZEH-SIZE

DEGAUSS

Degaussing is performed. Once degaussed, it takes approximately 4 minutes and 30 seconds to have degaussing function again. Wait until the lower OSD display indicates PLEASE.

RESET

Reset the on-screen setting status to the factory setting. (Press the UP button or DOWN button for one second or longer.) Note that the factory setting status is predetermined and not changeable.
