Satellite P770/P775/P770D/P775D

Do not use this equipment in the countries/regions which are not listed in the table below.

Available channel of Peer-to-peer connection by ad-hoc mode is Ch1- Ch11.

Connection with an access point by the Infrastructure mode is Ch1- Ch13.

As of Mar. 2011

Albania	Australia	Austria	Azerbaijan

Argentina	Bahrain	Belgium	Bolivia

Bosnia and	Bulgaria	Canada	Cambodia
Herzegovina

Chile	China	Colombia	Costa Rica

Croatia	Cyprus	Czech Republic	Denmark

Dominican Republic	Ecuador	Egypt	El Salvador

Estonia	Finland	France	Germany

Ghana	Greece	Guatemala	Hong Kong

Hungary	Iceland	India	Indonesia

Ireland	Italy	Japan	Jordan

Kazakhstan	Kenya	Kuwait	Kyrgyzstan

Latvia	Lebanon	Liechtenstein	Lithuania

Luxembourg	Macedonia	Malaysia	Malta

Mexico	Monaco	Montenegro	Netherlands

New Zealand	Norway	Oman	Panama

Pakistan	Papua New	Paraguay	Peru
	Guinea

Philippines	Poland	Portugal	Puerto Rico

Qatar	Romania	Saudi Arabia	Serbia

Singapore	Slovak Republic	Slovenia	South Africa

South Korea	Spain	Sri Lanka	Sweden

Switzerland	Taiwan	Thailand	Turkey

UAE	UK	Ukraine	USA
