Detailed Assembly (continued)

lens accessories-con't

Erecting Lens 1.5X (Select Models Only)

This accessory allows the user to view objects on land as you would naturally see them with your unaided eye. To use this accessory, simply place the erecting lens in between your eyepiece and the focusing mechanism on your telescope.

MFOCUSING TELESCOPE

1.After selecting the desired Eyepiece, aim Main Telescope Tube at a land-based target at least 200 yards away (e.g. A telephone pole or building). Fully extend focusing tube by turning Rack and Pinion Focusing Mechanism.

2.While looking through selected Eyepiece, slowly retract focusing tube by turning Rack and Pinion Focusing Mechanism until object comes into focus.

MALIGNING FINDERSCOPE

1.Look through Main Telescope Tube and establish a well-defined target. (see focusing telescope section).

2.Looking through finderscope, alternate tightening each Finderscope Adjustment Screw until center of finderscope is precisely centered on the same object already centered in main telescope tube’s field of view.

3.Now, objects located first with the Finderscope will also be centered in the field of view of the Main Telescope Tube.

MBATTERY INSTALLATION

Your Sky Tour Handset is powered by 3 AA batteries (user supplied) and are installed like you would with most remote controllers.

Your Illuminated Voyager Mount is powered by two CR1620 watch batteries (included). These batteries are installed by removing the battery cap located next to the illuminated dial power switches.

Never Look Directly At The Sun

With Your Telescope

Permanent Damage To Your Eyes

May Occur
