External Module Disassembly Process

IMPORTANT:The outside housing and color may vary from the mass produced model.

External Modules Disassembly Flowchart

The flowchart below gives you a graphic representation on the entire disassembly sequence and instructs you on the components that need to be removed during servicing. For example, if you want to remove the main board, you must first remove the keyboard, then disassemble the inside assembly frame in that order.

Turn off system and peripherals power

Disconnect power and signal cables from system

Remove

Battery

Remove

Lower Covers

Remove

ODD

Remove

DIMMs

Remove

WLAN

Remove

HDD

Screw List

Step



Screw



Quantity

Part No.













ODD Module

M2.5*8



1



86.AZ802.007















M2*3



2



86.AZ802.002













HDD Carrier

M3*3



4



86.AZ802.001













WLAN Module

M2.5*3



1



86.AZ802.006













Chapter 3

43

Page 53
