LCD Module Disassembly Process

LCD Module Disassembly Flowchart

Remove LCD

Panel from Main

Unit before proceeding

Remove

LCD Bezel

Remove

Inverter Board

Remove

LCD Panel

Remove

Camera Module

Remove

LCD FPC Cable

Remove

LCD Brackets

Remove

Antennas

Remove

Microphone

Screw List

Step	Screw	Quantity	Part No.

LCD Bezel	M2.5*6	4	86.AZ802.003
Inverter Board	M2.5*6	1	86.AZ802.003

LCD Panel	M2.5*6	2	86.AZ802.003

LCD Brackets	M2*3	8	86.AZ802.002

Chapter 3

81

Image 91

Acer 5737Z manual LCD Module Disassembly Process, LCD Module Disassembly Flowchart
