Cisco Systems 7906G, 7911G - page 154

Chapter7 Viewing Security Information, Model Info rmation, Status, and Statistics on the Cisco Unified IP Phone
Status Menu
7-10
Cisco Unified IP Phone 7906G and 7911G Administration Guide for Cisco Unified CallManager
OL-10008-01
Table7-4 Status Messages on the CiscoUnified IP Phones 7906G and 7911G
Message Description Possible Explanation and Action
BootP server used The phone obtained its IP
address from a BootP server
rather than a DHCP server.
None. This message is informational only.
Error Verifying
Config Info
The name-based and default
configuration file was not
found on the TFTP Server.
The configuration file for a phone is created
when the phone is added to the
Cisco UnifiedCallManager database. If the
phone has not been added to the
Cisco UnifiedCallManager database, the
TFTP server generates a CFG File Not Found
response.
•Phone is not registered with
Cisco UnifiedCallManager.
You must manually add the phone to
Cisco Unified CallManager if you are not
allowing phones to auto-register. See the
“Adding Phones with CiscoUnified
CallManager Administration” section on
page 2-14 for details.
•If you are using DHCP, verify that the
DHCP server is pointing to the correct
TFTP server.
•If you are using static IP addresses, check
configuration of the TFTP server. See the
“Network Configuration Menu” section
on page 4-7 for details on assigning a
TFTP server.
CFG TFTP Size Error The configuration file is too
large for file system on the
phone.
Power cycle the phone.
