Page 67

Media Memory Cards

2

1

1 release button

2

ExpressCard

Media Memory Cards

The 5-in-1 media memory card reader provides a fast and convenient way to view and share digital photos, music, and videos stored on a media memory card.

NOTE: A media memory card is not a bootable device.

The 5-in-1 media memory card reader reads the following media memory cards:

•Secure Digital (SD) card/SDIO

•MultiMediaCard (MMC)

•Memory Stick

•Memory Stick PRO

•xD-Picture Card

Installing a Media Memory Card

You can install a media memory card in the computer while the computer is running. The computer automatically detects the card.

Using Cards

67
