b.Press the OK key to confirm.
NOTE If you wish to select a media type that is currently not available, then you will need to create a new media type.
c.If required, select the NEW MEDIA ENTRY option using the
or
key and press the OK key (Refer to Manage media types).
Press the Cancel key to return to the SELECT MEDIA menu.
23.Install the tension bar. For full details of how to prepare the tension bars (Refer to Tension bars).
CAUTION Do not mount the flanges on the tension bar.
a.Adjust the tension bar (1) length to half the media width.
b.At the front of the printer, use the black media advance switch to feed enough media so that you can install the tension bar (1) in the slack area of the media.
NOTE Make sure the tension bar (1) is positioned in the center (widthwise) of the slack area of the media or the media may not feed smoothly .
NOTE If the media does not roll out smoothly, adjust the tension bar (1) length to be a little shorter than the width of the media.
24.Install another tension bar (fixing bar) in the tension bar guide at the front of the printer (feed side).
NOTE Refer to Tension bars for full details concerning the adjustment of the tension bar (fixing bar) length.
a.Adjust the tension bar (1) length to match the width of the media.
b.Fit flanges to each end of the tension bar.
