FH-3 Film Holder

The FH-3 allows strips of 35-mm film up to six frames in length to be scanned in the MA- 21 slide-mount adapter. The FH-3 can be used to scan film that can not be scanned in the SA-21, either because it is only one frame long or because it has excessive curl or damaged perforations ( 58).

Placing Film in the Holder

Open the holder



1 Holding the FH-3 with the Nikon logo

Nikon logo

uppermost, unlatch the holder snaps



and open the holder.





Snap

Place film in the holder



2 Place a strip of 35-mm film base up



(matte emulsion surface down) in the



bottom half of holder. Align the frame



to be scanned with an aperture in the



bottom half of the holder.





Aperture

Close the holder



3 Close the holder and align the ends of



the top and bottom halves. Latch the



holder cover and snap the top and bot-



tom halves together at both ends.





Snap shut

Align the film with an aperture



4 Slide the black plastic holder until the

Apertures

frame to be scanned is aligned with one



of the two apertures in the metal cover.



“Film Base”/”Emulsion Surface”

When film is examined under bright light, the image on the emulsion surface will be in slight relief, with bumps and hollows where the image has been developed. The opposite surface (the film base) will be reflective and smooth. Place the film in the holder base up.

50
