Page 72

Macintosh

1 Quit all applications

2 Insert the Nikon Scan CD into the CD-ROM drive A Nikon Scan 4 CD icon will appear on

the desktop. Double-click the icon to open the “Nikon Scan 4” window.

3 Double-click the Welcome icon in the “Nikon Scan 4” window

4 Choose a language

Alanguage-selection dialog will be displayed. Select a language and click Next.

5 Start the installer

The “Install Center” dialog will be dis- played. Open the “Software” panel and click Easy Install.

“Authenticate” (Mac OS X Only)

Clicking Easy Install in the software panel displays the “Authenticate” dialog shown at right. Enter the administrator name and password and click OK.

6 Click Accept

The license agreement will be displayed.

Click Accept.

63

Image 72
