Avaya P460 Chassis and Module Installation

Introduction

This chapter guides you through the basic hardware Installation process.

If you purchased an Avaya P460ML-CFG (Material code 700255003, PEC Code 4548-009), then one Supervisor Module, PSU and the Fan Module are already installed.

Operating Safety

Caution: The Avaya P460 switch and modules contain components sensitive to electrostatic discharge. Do not touch the circuit boards unless instructed to do so. Use appropriate anti-static equipment when handling the switch and modules.

Caution: Do not leave any slots open. Use the the blanking plates supplied to cover empty slots.

Caution: Do not insert any objects into the P460 chassis other than specifically designed Avaya products.

Warning: Keep your fingers and other objects clear of the fans when removing the Fan module. The fans continue to turn briefly after you have removed the module.

Danger: Keep your fingers and other objects clear of the fans when removing the tray as the fans continue to turn briefly after you have removed it.
