Page 17

EN 17

Setting satellite receiver's brand and channel

After installation, set the satellite receiver’s brand and channel correctly; otherwise, the Satellite Controller cannot work correctly.

Turn on the TV and select the video channel (or AV mode).

A Turn on the satellite receiver.

Turn on the satellite receiver’s power.

B Access the Main Menu screen on the recorder.

C Access the Initial Set screen.

Press rt to move the highlight bar (pointer) to “INITIAL SET”, then press OK or e.

D Access the Sat Control Set screen.

Press rt to move the highlight bar (pointer) to “SAT CONTROL SET”, then press OK or e.

E Enter the satellite receiver’s brand.

Press the appropriate number keys to enter the brand code from the list on page 18, then press OK.

If the brand code you entered is invalid, the code field will be reset. Enter the correct

brand code again.

If the recorder is in playback or

recording mode, you cannot set the brand code.

F Select the satellite receiver’s channel for testing.

Press the appropriate number keys to enter one of the channel positions on the satellite receiver, then press OK.

You can select the channel position between 1 to 999.

After pressing OK, the recorder enters the Test mode.

Press MENU.

Image 17
