DeWalt D28114R instruction manual Causes and Operator Prevention of Kickback

Page 5

•Always use proper guard with grinding wheel. A guard protects operator from broken wheel fragments and wheel contact.

•Accessories must be rated for at least the speed recommended on the tool warning label. Wheels and other accessories running over rated speed can fly apart and cause injury. Accessory ratings must be above listed minimum wheel speed as shown on tool nameplate.

•Hold tool by insulated gripping surfaces when performing an operation where the cutting tool may contact hidden wiring or its own cord. Contact with a “live” wire will make exposed metal parts of the tool “live” and shock the operator.

•Do not use Type 11 (flaring cup) wheels on this tool. Using inappropriate accessories can result in injury.

•ALWAYS WEAR EYE PROTECTION WHEN USING THIS TOOL.

•Use of accessories not specified in this manual is not recommended and may be hazardous. Use of power boosters that would cause the tool to be driven at speeds greater than its rated speed constitutes misuse.

•Do not use circular saw blades or any other toothed blades with this tool. Serious injury may result.

•When starting the tool with a new or replacement wheel, or a new or replacement wire brush installed, hold the tool in a well protected area and let it run for one minute. If the wheel has an undetected crack or flaw, it should burst in less than one minute. If the wire brush has loose wires, they will be detected. Never start the tool with a person in line with the wheel. This includes the operator.

•Avoid bouncing the wheel or giving it rough treatment. If this occurs, stop the tool and inspect the wheel for cracks or flaws.

•Direct sparks away from operator, bystanders or flammable materials. Sparks may be produced while cutting and/or grinding. Sparks may cause burns or start fires.

•Always use side handle. Tighten the handle securely. The side handle should always be used to maintain control of the tool at all times.

•Never cut into area that may contain electrical wiring or piping. Serious injury may result.

•Clean out your tool often, especially after heavy use. Dust and grit containing metal particles often accumulate on interior surfaces and could create an electric shock hazard.

•Do not operate this tool for long periods of time. Vibration caused by the operating action of this tool may cause permanent injury to fingers, hands, and arms. Use gloves to provide extra cushion, take frequent rest periods, and limit daily time of use.

•Direct the Dust Ejection System (DES) away from operator and coworkers. Serious injury may result (Fig. 1, K).

Causes and Operator Prevention of Kickback

•Kickback is a sudden reaction to a pinched, bound or misaligned wheel, wire brush or flap disc causing an uncontrolled cut-off tool to lift up and out of the workpiece toward the operator.

•When the wheel is pinched or bound tightly by the workpiece, the wheel stalls and the motor reaction drives the unit rapidly back toward or away from the operator.

•Kickback is the result of tool misuse and/or incorrect operating procedures or conditions and can be avoided by taking proper precautions as given below:

•Maintain a firm grip with both hands on the unit and position your body and arm to allow you to resist kickback forces. Kickback forces can be controlled by the operator, if proper precautions are taken.

•When wheel is binding, or when interrupting a cut for any reason, release the trigger and hold the unit motionless in the material until the wheel comes to a complete stop. Never attempt to remove the unit from the work or pull the unit backward while the wheel is in motion or kickback may occur. Investigate and take corrective actions to eliminate the cause of wheel binding.

English

3

Page 4 Page 6
Image 5
Page 4 Page 6
Contents Esmerilhador de Ângulo Pequeno 115 mm/125 mm 4-1/2/5 Page General Power Tool Safety Warnings Definitions Safety GuidelinesWork Area Safety Electrical SafetyAdditional Specific Safety Instructions for Grinders Specific Safety RulesPower Tool USE and Care ServiceCauses and Operator Prevention of Kickback Always Wear EYE Protection When Using this ToolVoltage Volts Total length of cord in meters m Intended USE Description FIGAssembly and Adjustments FeaturesAccessories Rotating the Gear CaseMounting and Removing Guard 2 and 5 Grinding WheelsMounting Guard Sanding Discs Wire WheelsGuards and Flanges 2and 5 Sanding Flap DiscsOperation Soft Start Feature SwitchesPaddle Switch LOCK-ON ButtonEdge Grinding with Grinding Wheels Mounting Sanding Backing Pads Using Sanding Backing PadsSurface Finishing with Sanding Flap Discs Using Wire CUP Brushes and Wire Wheels Mounting and Using Wire Brushes and Wire WheelsMounting Wire Brushes and Wire Wheels Mounting Cutting Wheels Mounting and Using Cutting Type 1 WheelsMounting Closed Type 1 Guard Cleaning Accessories MaintenanceUsing Cutting Wheels LubricationSeguridad Eléctrica Definiciones Normas De seguridadSeguridad DEL Área DE Trabajo USO Y Mantenimiento DE LA Herramienta Eléctrica Seguridad PersonalMantenimiento Instrucciones DE Seguridad Para Todas LAS OperacionesNormas Específicas DE Seguridad Español Antes DE Atención Colocar LO Siguiente Causas del retroceso y su prevención por parte del operadorEspañol Ténsion Volts Longitud del cable en metros m USO Previsto Descripción FIGComponentes Fig Ensamblado Y Ajustes Protección Contra Sobrecarga POWER-OFFCaracterísticas Rotación de la caja de engranajesMontaje Y Extracción DEL Protector AccesoriosProtector de montaje Cierre el cerrojo del protector para asegurar el mismo a Discos de lijar Discos de corte de 115 mm 2 y 125 mmDiscos de alambre Función DE Arranque Suave InterruptoresFuncionamiento Botón DE Bloqueo Interruptor DE PaletaBloqueo DEL EJE Montaje Y Extracción DE Discos CON CuboEsmerilado DE Bordes CON Discos DE Esmerilar Montaje DE Discos SIN CuboEsmerilado DE Superficie CON Discos DE Esmerilar Montaje DE LAS Almohadillas DE Respaldo Para Lijar Acabado DE Superficies CON Discos DE LijarUSO DE Almohadillas DE Respaldo Para Lijar Montaje y uso de cepillos de alambre y discos de alambreMontaje DEL Protector Cerrado Tipo Montaje y uso de discos de corte TipoUSO DE Ruedas DE Corte MantenimientoMontaje DE LOS Discos DE Corte Limpieza LubricaciónGuarde Estas Instruções Definições Diretrizes de SegurançaRegras Gerais de Segurança Reparos USO E Cuidados DA FerramentaUSE Sempre Proteção Para OS Olhos AO Usar Esta Ferramenta Instruções DE Segurança EspecíficasCausas de retrocesso e prevenção do operador Tensão Comprimento do cabo de extensão USO Devido DA Ferramenta Descrição FIGMontagem E Ajustes Proteção Contra Sobrecarga POWER-OFFRotação da caixa de engrenagem AcessóriosMontagem E Remoção do Protetor Montagem do protetorDiscos de Lixar Discos de Arame de AçoFuncionamento Discos de Lixar de 4-1/2 eInterruptor DE Palheta Protetores e FlangesFunção DE Arranque Suave Interruptor DE BloqueioMontagem DE Discos SEM Cubos Bloqueio do EixoMontage E Remoção DE Discos do Cubo Esmerilhamento DE Superfície COM Discos DE Esmerilhamento Esmerilhamento DE Superfície COM Discos DE EsmerilharUSO DE Almofadas DE Bloqueio DE Lixar Acabamento DE Superfície COM Discos DE LixaMontagem DAS Almofadas DE Bloqueio DE Lixar USO DE Escovas DE Copo DE FIO E Discos DE ARO Montagem e uso de escovas de fio de aço e discos de aroMontagem DE Escovas DE FIO DE AÇO E Discos DE ARO Montagem DE Protetor Fechado Tipo Montagem e uso de discos de corte TipoLubrificação ManutençãoLimpeza Montagem DE Disco DE CorteEspecificações Page Page Page JUN10 Part No. N082734 D28114 Copyright @ 2009, 2010 D Ewalt

D28114R specifications

The DeWalt D28114R is a powerful and versatile angle grinder designed for both professional and DIY applications. Engineered with a strong focus on performance and durability, this tool stands out in the crowded landscape of power tools. With a robust 12-amp motor, the D28114R generates an impressive no-load speed of up to 11,000 RPM, allowing users to tackle tough materials with ease. Whether grinding, cutting, or polishing, this grinder provides the power and efficiency needed for a variety of tasks.

One of the standout features of the DeWalt D28114R is its innovative dust ejection system. This technology helps to protect the motor and bearings from debris, which can extend the tool's lifespan and maintain optimal performance. The grinder's design includes a sealed switch, which prevents dust and debris from entering and damaging the internal components, ensuring long-lasting functionality.

The D28114R also prioritizes user comfort and safety. Its two-position side handle provides extra control and flexibility during use, accommodating both left- and right-handed users. Additionally, the tool features a lock-on switch for extended grinding sessions, allowing users to operate the grinder comfortably without constant pressure on the trigger.

Durability is a key characteristic of the DeWalt D28114R. Its high-quality construction features a heavy-duty housing that can withstand the rigors of demanding jobs. The grinder is designed to handle tough conditions, making it a reliable choice for construction sites and workshops alike.

Another notable feature of the D28114R is its quick-change wheel release, which allows users to easily switch out grinding wheels and accessories without the need for additional tools. This feature enhances productivity and minimizes downtime during projects.

Moreover, the D28114R is compatible with a variety of wheels and attachments, making it an adaptable tool for various applications. From cutting metal to grinding welds, this angle grinder is equipped to handle every job.

In summary, the DeWalt D28114R angle grinder combines power, durability, and user-friendly features, making it a top choice among professionals and DIY enthusiasts. With its powerful motor, innovative dust ejection system, and emphasis on safety, this tool delivers reliable performance in a versatile and convenient package. Whether you are a seasoned tradesperson or a weekend warrior, the D28114R is designed to exceed your expectations and enhance your productivity on the job.
