Schumacher INC-2405A owner manual Operating instructions, Calculating charge time

Page 12

12.2CHARGING STATUS (yellow and green) LED – The CHARGING STA- TUS LED glows yellow when the charger is charging and green when the battery is charged and in maintain mode.

LED Color/Flash Pattern Explanation

Red On

AC Power Present

Yellow On

Charging

Green On

Charge Complete

13.operating instructions

WARNING: Failure to follow instructions may cause damage or an explo- sion. Read the entire instruction manual before use.

13.1Make sure that the charger is unplugged from the AC outlet.

13.2Connect one of the three optional output cables to the charger output con- nector.

13.3Connect the other end of the output cable to the battery.

13.4Plug the charger into the AC outlet. The POWER ON (red) LED will glow to show that AC power is present. Then the green and yellow LED will blink once as a self-test to make sure that the LED is operating properly.

13.5After three seconds, the CHARGING (yellow) LED will glow to show that charging has begun. If none of the LEDs glow, or if the CHARGING (yel- low) LED does not glow, refer to the troubleshooting section. Charge time may vary from less than one hour to 12 hours.

13.6When charging is complete, the CHARGED (green) LED will glow and the charger will automatically go into maintain mode. If desired, the charger can now be unplugged from the AC outlet.

NOTE: If the battery has not reached at least 18-volts after five minutes of charging or at least 24-volts after four hours of charging, the charger will abort the charging process and turn the yellow LED off.

14.calculating charge time

To determine the time needed to fully charge your battery, you must first determine the battery’s charge level with a hydrometer or electronic

Percent-of-Charge Tester. The following table will help you convert hy- drometer readings to percent of charge values.

7

Image 12
