ELECTRONIC OVEN CONTROLS

This manual covers different models. The range you have purchased may have some or all of the items listed. The locations and appearances of the items shown here may not match those of your model.

ABC D E

F

O

N

M

L

K J I

H

G

A. Upper oven settings

E. Power preheat

I. Clock





M. Start/control lock

B. Oven display

F. Oven light

J. Kitchen timer



N. Temp/time “+” and “-”

C. Cook time

G. Self clean

K. Lower oven cancel



O. Lower oven settings

D. Delay start

H. Settings

L. Upper oven cancel





Display

When power is first supplied to the range, or if a power failure has occurred, 12:00 will appear on the display. See the “Clock” section to set time of day.

Cancel

Cancel stops any function except the Clock, Timer and Control Lock.

3.Press KITCHEN TIMER to start the timer. The colon stops flashing, and the time begins counting down. “TIMER Started” will scroll down the upper text display area.

The last minute of the timer countdown will be displayed in seconds.

At the end of the set time, one long beep will sound, and “TIMER End” will be displayed.

4.Press KITCHEN TIMER to clear the display.

NOTE: A reminder beep will sound until the Kitchen Timer is canceled.

Oven Lights

While the oven doors are closed, press OVEN LIGHT on the keypad to turn the lights on and off. Both oven lights will come on when either door is open. The oven lights will not come on during the Self-Clean cycle.

Kitchen Timer

The Kitchen Timer can be set in hours or minutes up to 9 hours and 59 minutes, and counts down the set time. The Kitchen Timer does not start or stop the oven.

To Set:

1.Press KITCHEN TIMER.

“Set TIMER” will display in the upper text area, and the clock will display “--:--” with the colon flashing.

2.Press the Temp/Time “+” or “-” pads until the desired time is reached.

To Cancel:

Press KITCHEN TIMER.

Clock

To change the clock between 12-hour and 24-hour format, see “12/24 Hour (Adjusting the Clock Format)” in the “Settings” section.

To Set the Time of Day:

Before setting, make sure the oven and Oven Timer are off.

1.Press CLOCK. “Set Time” will appear in the upper text area.

2.Press the Temp/Time “+” or “-” pads until the desired time is displayed.

3.“Press CLOCK” will appear in the upper text area, and “or Push START” will appear in the lower text area.

4.Press CLOCK or START. “Time Set” will appear in the upper text area. Once it disappears, the time is set.

10
