Page 6

Control Panel

Dishwasher

You can locate your model number on the tub wall just inside the door. Throughout this manual, features and appearance may var y from your model.

ZBD6800 and ZBD6880

1

ZBD0710

2

8







7

3

5

6

10

7

9

1

ZBD6890 and ZBD0700

8



1







2

3

2

4

3

5

6

4 5

10

6

9

7

10



9







Control Settings

6

1 Wash Cycles

Use the arrow pads to scroll through the wash cycles. The light above or next to the



selected pad will be ON to indicate which WASH CYCLE has been selected.

NOTE: This dishwasher is equipped with an ExtraCleanSensor with automatic temperature control; therefore, cycle time and total water consumption may vary depending on soil (heavy, medium, light) and temperature conditions.

ANTI

Heavy 9.1 gallons, 92 minutes

BACTERIAL

Medium 7.8 gallons, 89 minutes



Light 6.5 gallons, 87 minutes



This cycle raises the water temperature in the final rinse to sanitize your dishware.



The cycle length will vary depending on the temperature of your inlet water.



NOTE: The Anti-Bacterial cycle is monitored for sanitization requirements. If the cycle is



interrupted during or after the main wash portion or if the incoming water temperature is so



low that adequate water heating cannot be achieved, the sanitizing conditions may not be met.



In these cases, the sanitized light will not illuminate at the end of the cycle.

































ID

E

N T

I

NSF INTERNATIONAL











S











E

























A

Meets NSF Standard 184 Sanitization and Cleaning







R









L























































performance of household spray-type dishwashers.













NOTE: NSF certified residential dishwashers are not intended for licensed food establishments.









COOKWARE

Heavy 10.4 gallons, 102 minutes



Medium 9.1 gallons, 77 minutes



Light 7.8 gallons, 72 minutes



This cycle is meant for heavily soiled dishes or cookware with dried-on or baked-on soils. This



cycle may not remove burned-on foods. Everyday dishes are safe to be used in this cycle.









NORMAL

Heavy 9.1 gallons, 78 minutes



Medium 6.5 gallons, 60 minutes



Light 5.2 gallons, 49 minutes



This cycle is for medium/heavily soiled dishes and glassware.









SPEED CYCLE

Heavy 7.8 gallons, 37 minutes

(on some models)

Medium 6.5 gallons, 33 minutes



Light 5.2 gallons, 29 minutes



This cycle is for everyday dishes and glassware.
