Figure 3-11. Installing a Linking Board in a Mezzanine Card
5 | 4 |
|
2
3
6Flip the mezzanine assembly over and align over the two guide pins on the sled, see following image.
Figure 3-12. Installing a Mezzanine Assembly in a Sled
6
NOTE: The I/O screw bracket tab must be behind the mezzanine bracket.
7Align the linking board over the sled and insert as shown in the following image.
88
Installing System Components
