Status-light patterns

Table 9-1Status-light legend

Symbol for "light off"

Symbol for "light on"

Symbol for "light blinking"

Table 9-2Control-panel light messages

Light status

State of the printer

Action







Initialization/Startup

While in the Startup state, the Go, Ready, and Attention lights cycle (at the rate of 500 ms) one after another.

Reconfiguration Initialization

During the printer start up, you can request special initialization sequences that reconfigure the printer. When one of the sequences is requested, such as cold reset, the lights cycle as in the Initialization/Startup state.

Job Cancel

After the cancellation process has been completed, the printer returns to the Ready state.

During the Initialization, Reconfiguration, and Job Cancel processes, pressing buttons has no effect.

ENWW

Status-light patterns 67
