Display panel
Description | Spare part number |
|
|
HD+ WVA display panel | |
|
|
FHD WVA display panel for use only with LTE module | |
|
|
FHD WVA display panel | |
|
|
NOTE: The display panel can be removed separately from the display assembly.
Before removing the display panel, follow these steps:
1.Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system.
2.Disconnect all external devices connected to the computer.
3.Disconnect the power from the computer by first unplugging the power cord from the AC outlet and then unplugging the AC adapter from the computer.
4.Remove the battery (see Battery on page 48).
Remove the display panel:
1.Remove the display bezel:
a.Position the computer upright on a flat surface with the display panel open.
b.Remove the two rubber pads (1) that cover the display panel screws.
c.Remove the two Torx 9M2.5×5.0 screws (2) that secure the display bezel to the display enclosure.
Component replacement procedures 121
