IBM 4400 - page 240

240

Chapter 7Bar Codes

UPS Shipping Data Field

This syntax begins with seven encoded data characters followed by a date

(

). The first four characters are the Message Header and the next five are

the Transportation Data Format Header. The format of the Message Header

is : “[)>Rs”. The Transportation Data Format Header is : “01Gs<

>” where

> is the year, and “G's” and “R's” are control characters. The struct ure is

shown in Table 72.

Table 72. UPS Shipping Data Fields

Character

Positions Title Data

0 - 3 Message Header [)>Rs

4 - 8 TransportationData

Format Header 01Gs<

9 - 17 PostalCo de 9 Digit Numeric for US

6 Digit Alphanumeric for

Canada

18 Separator Gs

19 - 21 Country Code Numeric

22 Separator Gs

23 - 25 Class of Service Numeric

26 Separator Gs

27 - ... Secondary Message As per the UPS** Guide

To Bar cod ing
