Editing Templates cont...

TANDBERG CONTENT SERVER ADMINISTRATOR GUIDE

The Download Section

Output Layout

Joined—creates one video output consisting of the main source on the left and the dual to the right joined as one video file. Dual will be displayed as a poster when it is not activated.

Switching—creates one video output. The Main video is replaced by the Dual when Dual is activated, then replaced by Main when Dual is stopped.

Picture in picture—creates one video with main picture inserted into the Dual. When Dual is activated, the Main video will transition to the selected location, displaying the Dual video. On turning off Dual, the Main will transition to take up the entire video.

Movie Settings

Formats—there are three formats available. Windows Media for playback using Windows Media Player on a Personal Computer, MPEG4 for playback using QuickTime on a Macintosh and Real Media for playback using Real Media Player. Either 1, 2 or 3 formats can be chosen.

Conference Sizes—as files will be downloaded and viewed on a computer, the internet connection is not then an issue, other than the time it takes to download them. The advantage is for users with poor Internet connections as they can watch the files, once downloaded, without being connected to the Internet.

One or two sizes need to be selected to create an output to be viewed in the Player.
