Dubbing

1.Find a point on your recorded cassette slightly before the section you want to copy and set it to playback pause mode.

2.Press the REC PAUSE button.

•S-video and A/V IN/OUT terminals automatically work as input terminals.

•The camera enters record pause mode.

3.Start playback on the other device or turn on the TV to see the desired program while you monitor the picture.

4.Press the pause button.

•Recording starts.

5.When you get to the point where you want to stop recording, press the stop button or the pause button.

•Recording stops.

6.Stop playback on the other device.

• You can monitor the picture in the viewfinder or LCD.

Editing

84

Image 84
